Features:

1. The latest design, and apply to the connection of communication socket between equipment room and workaround

2.IDC line clip: environment-friendly phosphor bronze, 250 times min

3. Contact pins are made of environment-friendly phosphor bronze, gold-plated 30U ", insertion time is 1000 times min.

4. Can be compatible to lower categories of the system to avoid loss of investment.

5. Contact resistance : under normal atmospheric pressure, the contact resistance is less than 2.5 MΩ

6. Insulation strength: under normal atmospheric , the insulation resistance is more than 1000 MΩ

7. Dielectric strength when DC 1000V (or AC 700V) is applied, there is no evident arc and spark-over for 1minute

8. Material of Plastic body is PC, and the fire rating is UL 94-V1

9.Available in Cat3,T568 A ,T568 B wiring .meeting every cabling requirement

10.Accept 22-26 AWG solid with a insulation diameter of 0.4-0.6 mm

11.Match ed with 86-type face plate
